For example, if the information is printing too far to the right on your tags, then you can drag the fields over on the template to the left, and then click 'Save' on the template.

Printer zebra gx430t trial#

This may require some trial and error, but you will certainly get it right eventually. (You only need to 'Edit' the already existing tag template on your system, you do not need to create a brand new one) If this is correct, you may need to find tune your Stock Tag Template, instructions for doing this can be found here: If you are finding that the alignment is off be sure you have set the width and height correctly as per the 'Labels' step.

Next to your printers template click Set Default, a confirmation notice will pop up to confirm the change.

Under the Name Column find the template that has your Stock Labels model number within the name.

Click Printing from the left side bar menu.

Open the Utilities page of Swim from the home screen.

To ensure you have the correct template set to match your printer model, follow the below steps. The T550 use 78mm width by 15mm height.īy default Swim will have the required stock tag templates listed for you to use, these templates will only work for you correctly if you have selected to order Stock Tag Labels directly from Swim Support. The T985W labels use 78mm width by 25mm height.

Printer zebra gx430t full#

The width measurement is always the full width of an entire roll (including the left and right non-printable areas.)Īs mentioned above we do provide all clients the option of ordering labels directly from us which we already provide the label specifications. From there you half the non-printable are and add this together with the original height measurement. To get the correct measurements of your labels you simply need to measure the full width of the roll and the full height of the printable area whilst adding in the non-printable area. If you do decide to order your labels from another supplier you just need to check they will be compatible with your printer, however, and measurements of the labels will need to be taken. Labels for your printer can be ordered directly through the Swim support system to all our clients, we do provide clients with the following labels:

Untick the box next to “Continue wizard with advance settings”.On the Media page set the print mode as Transfer and the media type as Web Sensing.Next you are presented with Speed and Darkness settings by default you shouldn’t have to change any settings here however ensure that you have the speed box set at 50.8 and the darkness set at 30 then click next.Click on the orientation drop down menu, select normal, then click next.(Note if you have ordered labels directly from Swim you can find your measurements here. For the T510 or T550 the measurements are 78mm width by 15mm height. The measurements for the Swim supplied TSR985W tag model is 78mm width by 25mm height. From the popup window enter in the width and height of your label you will be using with your Zebra printer ensure that you have the unit of measurement set to millimetres.Under Print Configuration click on Configure Printer Settings.Click on your Zebra Printer to highlight it blue.Your printer should be set on the following settings to give a clean and correct print each time.

Printer zebra gx430t Pc#

Restart your PC to apply the settings just installed.Įnsuring your printer is set up on the right settings is a vital part of making sure your printer is configured to function correctly.

Once completed click finish to close the installation window.

Ensure that under “Install this program for” the button it ticked next to “Anyone who uses this computer” click next to begin the installation on the following page.

Printer zebra gx430t install#

Click next and leave the install directory as its default there is no need to change the settings on this page just click next again to continue.

Click Start button from the installation window and tick the box accepting the licencing agreement presented to you on the following page.

Printer zebra gx430t download#

Once the download has completed open the download package from the download arrow in the top right corner of Firefox.Under the Download Tab click the download link next to Zebra setup utilities.Select your printers model from the drop down menu.Note: The following guide only deals with the Zebra Stock Tag printer, which is the only brand of printer currently sold by TJS/Swim.
